SUPFLUX-P Series High Flow Cartridge Filter
Products
SUPFLUX-P Series High Flow------Ideal Alternative for Pall UltiPleat

SUPFLUX-P Series High Flow cartridge filter is made by 100% Polypropylene material. As outside diameter 6’’ large surface pleated cartridge filter, It own great dirty holding capacity and high flow rate.

Feature:

  1. 100% Polypropylene, Glass Filled and SS Material
  2. Fewer cartridge and less time to assemble
  3. Handle design makes quick change
  4. Large surface area for longer lifespan

Application:

  • Sea Water Desalination
  • Amine
  • Petro Chemical
  • Solvent based
  • paints & coatings
  • Power Plant

Material Construction:

Filter Media PP Pleated, GF Pleated,

PP Melt Blown
Supporter PP No Woven Fiber
Cage PP Cage, Net Cage,

SS Cage,

Bonding Cage,

Glass Filled Cage,

Nylon Filled Cage

Specification:

Length 20’’,40’’,60’’
Micron Rate 1μm~20μm
Diameter -OD 152mm

Operation Condition:

Max. Pressure Drop 0.38Mpa@25℃

0.25Mpa@120℃
Max. Working Temp. 80℃
Change-Out Pressure Drop 0.25Mpa

Order Information:

Application Type Material Length Micron Core Sealing Cage
C HF PP1 40 F N S PP
F-Food&Beverage

C-Chemical

I-Industrial Water Treatment

 HF-High Flow PP1-Norminal PP PP2-Absolute PP

PP3-Thick Meida

PG-Glass Fiber

 20-20‘’

40-40‘’

60-60‘’

 F-1.0μm

H-5.0μm

I-10.0μm

J-20.0μm

 N=No Core

P-PP core

 S-Silicone

E-EPDM

N-NBR

V-Viton

U-U Cup

 PP= PP Cage

NC= Net Cage

SS=SS Cage

BC=Bonding Cage

GF=Glass Filled Cage

NF=Nylon Filled Cage

PE-PE Cage
